D24S Blower Pulley Deformation & Overhaul Repair

1. Project Overview

• Industry: Chemical

• Equipment: D24S Blower

• Failure Type: Pulley Groove Deformation / Routine Overhaul

• Year: 2023

2. Project Background

The D24S blower was used in a chemical plant and required routine maintenance.

During inspection, deformation in the pulley groove was identified, which could affect transmission stability.

3. Problem / Failure Analysis

• Pulley groove deformation

• Risk of belt misalignment

• Reduced transmission efficiency

• Potential for long-term mechanical instability

4. Root Cause

• Long-term mechanical wear

• Stress concentration in pulley structure

• Lack of timely maintenance

5. Our Solution

Procetek provided a comprehensive overhaul solution:

• Disassembly of blower system

• Inspection of pulley and transmission components

• Repair or replacement of deformed pulley

• Reassembly with corrected alignment

• Operational testing

6. Scope of Work

• Equipment dismantling

• Pulley inspection and correction

• Component repair/replacement

• Reassembly and testing

7. Before & After Condition

Before Repair

• Deformed pulley groove affecting operation

During Repair

• Disassembly and inspection

Left:  Disassembled                                                          Right:  Cleaned and Overhauled

After Repair

• Restored pulley and system alignment

After repair, the transmission system returned to stable and efficient operation.

8. Results

• Restored transmission stability

• Improved operational efficiency

• Extended equipment service life

• Reduced risk of further mechanical damage

9. Why It Worked

• Accurate identification of mechanical deformation

• Proper component repair and alignment

• Strong maintenance engineering capability

10. Conclusion

Routine maintenance combined with targeted repair can effectively prevent major equipment failure and extend service life.
